| Varenummer | LQ170K1LW02 |
| Mærke | SHARP |
| Størrelse | 17.0 |
| Ansøgning | GM |
| Løsning | 1280×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 600:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ170K1LW02 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×768 , WXGA |
| visningstilstand | P-MVA, Normally Black, Transmissive |
| aktivt område | 369.6×221.76 mm |
| omrids | 413.8×259×16 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | GM |
