| Varenummer | LQ170E1LG18 |
| Mærke | SHARP |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 450:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ170E1LG18 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 337.92×270.336 mm |
| omrids | 358.5×296.5×17.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| rohs: | |
| Ansøgning | DMPC |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| LC170WXN-SAA1 | LG Display | 17.0 | 1366×768 |
| LQ170E1LG11 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LQ170K1LW02 | SHARP | 17.0 | 1280×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM240WU8-SLD4 | LG Display | 24.0 | 1920×1200 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
