| Varenummer | LQ281L1LW12 |
| Mærke | SHARP |
| Størrelse | 28.1 |
| Ansøgning | IA |
| Løsning | 2048×2048 |
| Sammensætning | LCM |
| Lysstyrke | 225 |
| CR | 450:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ281L1LW12 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 28.1 inch |
| løsning | 2048(RGB)×2048 |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 503.808×503.808 mm |
| omrids | 594×594×83 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 225 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (8 ch, 8-bit), 160 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | IA |
| LQ281L1LW11 | SHARP | 28.1 | 2048×2048 |
| LQ281L1LW12 | SHARP | 28.1 | 2048×2048 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LM-CC53-22NDK | SANYO | 10.4 | 640×480 |
| LM-CJ53-22NAK | SANYO | 10.4 | 640×480 |
| LQ085Y3DW01 | SHARP | 8.5 | 800×480 |
| LTA121B860F | TOSHIBA | 12.1 | 800×600 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
