| Varenummer | LQ085Y3DW01 |
| Mærke | SHARP |
| Størrelse | 8.5 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ085Y3DW01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.5 inch |
| løsning | 800×480(RGB) , WVGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 184.8×110.88 mm |
| omrids | 210×134 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S4PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
