| Varenummer | LQ315D1LG9D |
| Mærke | SHARP |
| Størrelse | 31.5 |
| Ansøgning | DMPC |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ315D1LG9D |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 697.92×392.58 mm |
| overflade | Antiglare, Hard coating (3H), Antireflection |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 1.07B (10-bit), Adobe |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (8 ch, 10-bit) |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
