| Varenummer | LQ315T3LZ23 |
| Mærke | SHARP |
| Størrelse | 31.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ315T3LZ23 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 780×450 mm |
| overflade | Antiglare (Haze 23%), Hard coating (2H), Antireflection |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193173% |
| responstid | 12/12 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 18 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 37 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
