| Varenummer | M201UN03 V0 |
| Mærke | AUO |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 1600×1200 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M201UN03 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1600(RGB)×1200 , UXGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 408×306 mm |
| omrids | 432×331.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| responstid | 11/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
