| Varenummer | LS012B7DH02 |
| Mærke | SHARP |
| Størrelse | 1.2 |
| Ansøgning | SW |
| Løsning | 240×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Monochrome |
| Baggrundsbelysning | No B/L |
| Interface | SPI |
| panel mærke | SHARP |
| panel model | LS012B7DH02 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 1.2 inch |
| løsning | 240×240 |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 30.48×30.48 mm |
| omrids | 35.78×36.53 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | |
| kontrastforhold | 24:1 (Typ.)(Reflective) |
| vise farver | Monochrome (1-bit) |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/60/60 (Min.)(CR≥3)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | No B/L |
| signal interface | SPI, 10 pins |
| indgangsspænding | 3.0/3.0V (Typ.)(VDD/VDDA) |
| Ansøgning | SW |
