| Varenummer | LSC460HW01 |
| Mærke | Samsung |
| Størrelse | 46 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 5000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LSC460HW01 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 46 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | SVA, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| omrids | 1036.08×591.41 mm |
| overflade | Antiglare (Haze 2%), Hard coating (2H) |
| glas dybde | 0.70+0.70 mm |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Dithering) |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz (60Hz Input) |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
