| Varenummer | LT133EE10300 |
| Mærke | TOSHIBA |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Toshiba Mobile Display |
| panel model | LT133EE10300 2 Compatible model |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 293.42×164.97 mm |
| omrids | 307.6×183.1×5.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B133EW03 V1 | AUO | 13.3 | 1280×800 |
| B133EW03 V2 | AUO | 13.3 | 1280×800 |
| LP133WX2-TLC1 | LG Display | 13.3 | 1280×800 |
| LQ133M1JW03 | SHARP | 13.3 | 1920×1080 |
| LT133EE09400 | TOSHIBA | 13.3 | 1366×768 |
| LT133EE09C00 | TOSHIBA | 13.3 | 1366×768 |
| LT133EE10300 | TOSHIBA | 13.3 | 1366×768 |
| LTN133AT23-C01 | Samsung | 13.3 | 1366×768 |
| M133NWN1 R1 | IVO | 13.3 | 1366×768 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| B133XTN01.6 HW0A | AUO | 13.3 | 1366×768 |
| LP140WH2-TLL1 | LG Display | 14.0 | 1366×768 |
| LP141WX3-TLN2 | LG Display | 14.1 | 1280×800 |
| LP150X05-A2C1 | LG Display | 15.0 | 1024×768 |
| LTD121EW6S | TOSHIBA | 12.1 | 1280×800 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTN150XB-L03 | Samsung | 15.0 | 1024×768 |
| LTN154P3-L02 | Samsung | 15.4 | 1680×1050 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| N156B6-L3D | Innolux | 15.6 | 1366×768 |
