| Varenummer | LTA149B780F |
| Mærke | TOSHIBA |
| Størrelse | 14.9 |
| Ansøgning | IA |
| Løsning | 1280×390 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Toshiba Matsushita |
| panel model | LTA149B780F |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.9 inch |
| løsning | 1280(RGB)×390 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 360.94×109.98 mm |
| omrids | 407.5×136×20.5 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/45/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
