| Varenummer | TX31D37VM0CAA |
| Mærke | KOE |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HITACHI |
| panel model | TX31D37VM0CAA |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | IPS Pro, Normally Black, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 280×210×13.08 mm |
| overflade | |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S8PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| B121EW10 V2 | AUO | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LQ121S1LG55 | SHARP | 12.1 | 800×600 |
| LT121AC53000 | TOSHIBA | 12.1 | 466×350 |
| LT121SL-105 | Samsung | 12.1 | 800×600 |
| LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
| LTN121AP03-002 | Samsung | 12.1 | 1280×800 |
| NL8060BC31-01 | NLT | 12.1 | 800×600 |
| TX31D32VM2AAA | KOE | 12.1 | 800×600 |
| TX31D37VM0CAA | KOE | 12.1 | 800×600 |
| AA104XD02 | Mitsubishi | 10.4 | 1024×768 |
| DLC1040ABG-3 | Other | 10.4 | 800×600 |
| DLH1055 | LiteMax | 10.4 | 1024×768 |
| EL640.480-AG1 ET | Lumineq | 8.1 | 640×480 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| LM64P89L | SHARP | 10.4 | 640×480 |
| LQ104V1LG61 | SHARP | 10.4 | 640×480 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
