| Varenummer | LTA460HF03-T02 |
| Mærke | Samsung |
| Størrelse | 46 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTA460HF03-T02 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 46 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| overflade | |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 10/6 (Typ.)(Tr/Td); 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| signal interface | LVDS (4 ch, 10-bit), 92 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
