| Varenummer | LTB218JP01-001 |
| Mærke | Samsung |
| Størrelse | 21.8 |
| Ansøgning | GM |
| Løsning | 1366×1024 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTB218JP01-001 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.8 inch |
| løsning | 1366(RGB)×1024 |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 440×340 mm |
| omrids | 469.5×366.23×31.1 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | GM |
| LTB218JP01-001 | Samsung | 21.8 | 1366×1024 |
| A141EW01 V0 | AUO | 14.1 | 1280×800 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| LQ104V1DW01 | SHARP | 10.4 | 640×480 |
| LQ104V1LG92 | SHARP | 10.4 | 640×480 |
| LQ121S1LG75 | SHARP | 12.1 | 800×600 |
| LQ156M1LG21 | SHARP | 15.6 | 1920×1080 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LT100AA40000 | TOSHIBA | 10.0 | 800×600 |
| P64CN1 | E Ink | 6.4 | 320×234 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
