| Varenummer | LT100AA40000 |
| Mærke | TOSHIBA |
| Størrelse | 10.0 |
| Ansøgning | GM |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 430 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Toshiba Mobile Display |
| panel model | LT100AA40000 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.0 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 202.8×152.1 mm |
| omrids | 227×172 mm |
| overflade | Hard coating |
| lysstyrke | 430 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | GM |
