| Varenummer | LTI216XM01 |
| Mærke | Samsung |
| Størrelse | 21.6 |
| Ansøgning | DID |
| Løsning | 960×960 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI216XM01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.6 inch |
| løsning | 960(RGB)×960 |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 387.36×387.36 mm |
| omrids | 393.26×393.26×56 mm, Videowall Seam 5.9 mm |
| overflade | Antiglare (Haze 44%) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DID |
