| Varenummer | LD470DUN-TFC1 |
| Mærke | LG Display |
| Størrelse | 47 |
| Ansøgning | DID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1200:1 |
| Farver | 1.06B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LD470DUN-TFC1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 47 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1039.68×584.82 mm |
| omrids | 1044.9×590×52.8 mm, Videowall Seam 5.2 mm |
| overflade | Antiglare (Haze 10%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 1.06B (8-bit + Dithering), CIE193168% |
| responstid | 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DID |
