| Varenummer | LTI520HB01 |
| Mærke | Samsung |
| Størrelse | 52 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI520HB01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 52 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 1152×648 mm |
| omrids | 1192×688 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 14/8 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 28 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SCC1 | LG Display | 42 | 1920×1080 |
| LK695D3LA18 | SHARP | 70 | 1920×1080 |
| LTI400HA06 | Samsung | 40 | 1920×1080 |
| LTI430LA01 | Samsung | 43 | 1920×480 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI460HN05 | Samsung | 46 | 1920×1080 |
| LTI550HN04 | Samsung | 55 | 1920×1080 |
| P320HVN01.1 | AUO | 31.5 | 1920×1080 |
| RX415TXP01 | ROGIN | 41.5 | 1920×540 |
