| Varenummer | LTI430LA01 |
| Mærke | Samsung |
| Størrelse | 43 |
| Ansøgning | PID |
| Løsning | 1920×480 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI430LA01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 43 inch |
| løsning | 1920(RGB)×480 |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 1059.84×264.96 mm |
| omrids | 1084×289 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 15/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| HV430FHB-N4A | BOE | 43 | 1920×1080 |
| LC430DUE-FJM1 | LG Display | 43 | 1920×1080 |
| LC430EGG-FHM1 | LG Display | 43 | 3840×2160 |
| LC430EQL-SHA2 | LG Display | 43 | 3840×2160 |
| LC430EUE-FHM1 | LG Display | 43 | 1920×1080 |
| LTA430HN01 | Samsung | 43 | 1920×1080 |
| LTI430LA01 | Samsung | 43 | 1920×480 |
| LTI430LA02 | Samsung | 43 | 1920×480 |
| RX430HD02-DC15 | ROGIN | 43 | 1920×1080 |
| T430QVN01.0 CELL | AUO | 43 | 3840×2160 |
| LD550EUE-FHB1 | LG Display | 55 | 1920×1080 |
| LTI370LN03 | Samsung | 37 | 1920×540 |
| LTI520HB02 | Samsung | 52 | 1920×1080 |
| LTI550HJ05 | Samsung | 55 | 1920×1080 |
| LTI570HD01 | Samsung | 57 | 1920×1080 |
| LTI700HD01-001 | Samsung | 70 | 1920×1080 |
| LTI700HD01-006 | Samsung | 70 | 1920×1080 |
| P320HVN02.1 | AUO | 31.5 | 1920×1080 |
| P420HVN01.0 | AUO | 42 | 1920×1080 |
| RX320HD01-DC15 | ROGIN | 31.5 | 1920×1080 |
