| Varenummer | LTM170E8-L01 |
| Mærke | Samsung |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM170E8-L01 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 337.92×270.336 mm |
| omrids | 354.9×290.3×13.3 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 1500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| LM150X08-TL01 | LG Display | 15.0 | 1024×768 |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| M185XW01 V1 | AUO | 18.5 | 1366×768 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| TM150XG-26L06A | SANYO | 15.0 | 1024×768 |
