| Varenummer | TX43D14VC0CAB |
| Mærke | KOE |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 230 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | HITACHI |
| panel model | TX43D14VC0CAB |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | IPS-Pro, Normally Black, Transmissive |
| aktivt område | 337.92×270.336 mm |
| omrids | 368×306 mm |
| overflade | Antiglare |
| lysstyrke | 230 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
