| Varenummer | LTM190ET01 |
| Mærke | Samsung |
| Størrelse | 19.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM190ET01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 396×324×17 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L05 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM190M2-L31(Glare) | Samsung | 19.0 | 1440×900 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| LTM170E8-L01 | Samsung | 17.0 | 1280×1024 |
| LTM220MT05 | Samsung | 22.0 | 1680×1050 |
| M215HJJ-L30 Rev.B1 | Innolux | 21.5 | 1920×1080 |
| M236HJJ-L31 | Innolux | 23.6 | 1920×1080 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
