| Varenummer | LTM220MT12 |
| Mærke | Samsung |
| Størrelse | 22.0 |
| Ansøgning | DMPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM220MT12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 22.0 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 473.76×296.1 mm |
| omrids | 493.7×320.1×10.7 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| LM171W02-TLB2 | LG Display | 17.1 | 1440×900 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| LTM240CL04 | Samsung | 24.0 | 1920×1200 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M240HW02 V6 | AUO | 24.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
| QD15XL13 Rev.01 | QDI | 15.0 | 1024×768 |
