| Varenummer | M270HW02 V3 |
| Mærke | AUO |
| Størrelse | 27.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 5000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M270HW02 V3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 27.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | VA, Normally Black, Transmissive |
| aktivt område | 597.6×336.15 mm |
| omrids | 630×368.2×10.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 7/5 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | 17S4PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270HW01 V1 | AUO | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| IAQX10M | IDTech | 15.0 | 2048×1536 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| LTM190ET01 | Samsung | 19.0 | 1280×1024 |
| LTM230HT05 | Samsung | 23.0 | 1920×1080 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
