| Varenummer | LTN156KT06-801 |
| Mærke | Samsung |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 300:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN156KT06-801 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.16×193.59 mm |
| omrids | 359.3×222.45×4 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 16.2M (6-bit + FRC), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S4PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| LQ156D1JW02 | SHARP | 15.6 | 3840×2160 |
| LTN156AT02-D03 | Samsung | 15.6 | 1366×768 |
| LTN156KT01-001 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| LTN156KT02-301 | Samsung | 15.6 | 1600×900 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| N156B3-L0A | Innolux | 15.6 | 1366×768 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| LP141WX3-TLN4 | LG Display | 14.1 | 1280×800 |
| LP154WE3-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LQ164M1LG4B | SHARP | 16.4 | 1920×1080 |
| LTN160AT02-002 | Samsung | 16.0 | 1366×768 |
| N121I3-L03 | Innolux | 12.1 | 1280×800 |
| N140FGE-E32 | Innolux | 14.0 | 1600×900 |
