| Varenummer | LTN156KT01-W01 |
| Mærke | Samsung |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN156KT01-W01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | LVDS (2 ch, 6-bit) |
| Ansøgning | NBPC |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| LTN156AT05-H07 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-201 | Samsung | 15.6 | 1920×1080 |
| LTN156KT01-001 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| LTN156KT02-301 | Samsung | 15.6 | 1600×900 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| N156BGE-E41 | Innolux | 15.6 | 1366×768 |
| CLAA140WA01 | CPT | 14.0 | 1280×768 |
| CLAA154WP05A | CPT | 15.4 | 1440×900 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| HN133WU1-100 | BOE | 13.3 | 1920×1080 |
| LP156WH2-TLRA | LG Display | 15.6 | 1366×768 |
| LTD121EWRF | TOSHIBA | 12.1 | 1280×800 |
| LTN154X3-L04 | Samsung | 15.4 | 1280×800 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| TM133XG-02L07A | SANYO | 13.3 | 1024×768 |
| VVX16T010J00 | Panasonic | 15.5 | 2880×1620 |
