| Varenummer | LTN184KT01-J01 |
| Mærke | Samsung |
| Størrelse | 18.4 |
| Ansøgning | NBPC |
| Løsning | 1680×945 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN184KT01-J01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.4 inch |
| løsning | 1680(RGB)×945 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.24×229.635 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | LVDS (2 ch, 6-bit) |
| Ansøgning | NBPC |
| LTN184HT05-D01 | Samsung | 18.4 | 1920×1080 |
| LTN184KT01-101 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-A01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
| B141XN01 V0 | AUO | 14.1 | 1024×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LTN150PG-L04 | Samsung | 15.0 | 1400×1050 |
| LTN154X3-L06-6 | Samsung | 15.4 | 1280×800 |
| LTN156AT09-B02 | Samsung | 15.6 | 1366×768 |
| N121IB-L05 Rev.C1 | Innolux | 12.1 | 1280×800 |
| N154I4-L04 | Innolux | 15.4 | 1280×800 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
| QD15XL06 Rev.01 | QDI | 15.0 | 1024×768 |
