| Varenummer | N184H4-L04 |
| Mærke | Innolux |
| Størrelse | 18.4 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 650:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N184H4-L04 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.4 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.96×230.04 mm |
| omrids | 422.5×248×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B133XW03 V0 | AUO | 13.3 | 1366×768 |
| B140XTN03.3 HW0A | AUO | 14.0 | 1366×768 |
| HV150UX1-101 | HYDIS | 15.0 | 1600×1200 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP173WF1-TLA1 | LG Display | 17.3 | 1920×1080 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT35-H01 | Samsung | 15.6 | 1366×768 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
