| Varenummer | LTN190W1-L01 |
| Mærke | Samsung |
| Størrelse | 19.0 |
| Ansøgning | NBPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN190W1-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.24×255.15 mm |
| omrids | 424.5×273.5×11.5 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 10 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | NBPC |
| AA190EA01 | Mitsubishi | 19.0 | 1280×1024 |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| HT190WG1-600 | BOE | 19.0 | 1440×900 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| LTN190W1-L01 | Samsung | 19.0 | 1680×1050 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M190EG01 V0 | AUO | 19.0 | 1280×1024 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| SVA190WX01TB | SVA-NEC | 19.0 | 1440×900 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B140XTN03.1 | AUO | 14.0 | 1366×768 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| LP171WP4-TLR1 | LG Display | 17.1 | 1440×900 |
| LP171WX2-A4K7 | LG Display | 17.1 | 1440×900 |
| LTN104S2-L01 | Samsung | 10.4 | 800×600 |
| LTN133AT17-H01 | Samsung | 13.3 | 1366×768 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
| TM121XG-02L01 | SANYO | 12.1 | 1024×768 |
