| Varenummer | M215H1-L02 |
| Mærke | Innolux |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | M215H1-L02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×268.11 mm |
| omrids | 495.6×292.2×16.85 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 1.3/3.7 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| M215H1-L02 | Innolux | 21.5 | 1920×1080 |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| M215HGJ-P02 | Innolux | 21.5 | 1920×1080 |
| M215HNE-L30 | Innolux | 21.5 | 1920×1080 |
| M215HW01 V0 | AUO | 21.5 | 1920×1080 |
| M215HW01 V6 | AUO | 21.5 | 1920×1080 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M215HW02 V0 | AUO | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM215WF4-TLA3 | LG Display | 21.5 | 1920×1080 |
| LM250WF2-TLA1 | LG Display | 25.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| M190CGE-L20 | Innolux | 19.0 | 1440×900 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| SVA150XG10TB | SVA-NEC | 15.0 | 1024×768 |
