| Varenummer | LM270WF5-SSC1 |
| Mærke | LG Display |
| Størrelse | 27.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM270WF5-SSC1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 27.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 597.888×336.312 mm |
| omrids | 617.1×361.3×14.75 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM270WF2-TLA5 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLN2 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDC2 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SLC1 | LG Display | 27.0 | 2560×1440 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| IAWS64 | IDTech | 20.1 | 1680×1050 |
| LM150X06-A3M2 | LG Display | 15.0 | 1024×768 |
| LM230WFA-SLZ1 | LG Display | 23.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDDA | LG Display | 27.0 | 2560×1440 |
| M156MWR1 R0 | IVO | 15.6 | 1366×768 |
| M200RW01 V3 | AUO | 20.0 | 1600×900 |
| MT220WW01 V.6 | Innolux | 22.0 | 1680×1050 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
