| Varenummer | M215XTN01.0 |
| Mærke | AUO |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M215XTN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×267.96 mm |
| omrids | 495.6×292.2 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 3.8/1.2 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S4PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| CLAA215FA04 V4 | CPT | 21.5 | 1920×1080 |
| HR215WU1-100 | BOE | 21.5 | 1920×1080 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LC215EUN-SCA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| M215H1-L02 | Innolux | 21.5 | 1920×1080 |
| M215HTN01.0 | AUO | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| M215XTN01.0 | AUO | 21.5 | 1366×768 |
| ITQX20H | IDTech | 20.8 | 2048×1536 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LM171WX3-TLC2 | LG Display | 17.1 | 1440×900 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190E0A-SLA1 | LG Display | 19.0 | 1280×1024 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M185XTN01.3 | AUO | 18.5 | 1366×768 |
| M190CGE-L20 | Innolux | 19.0 | 1440×900 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
