| Varenummer | M260J2-L07 |
| Mærke | Innolux |
| Størrelse | 25.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 750:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | M260J2-L07 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 25.5 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 550.08×343.8 mm |
| omrids | 582×375.6 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 750:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 1/4 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFL |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
