| Varenummer | IAWS64 |
| Mærke | IDTech |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 210 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | TMDS |
| panel mærke | IDTech |
| panel model | IAWS64 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | DD-IPS, Normally Black, Transmissive |
| aktivt område | 433.44×270.9 mm |
| omrids | 486.2×307 mm |
| overflade | |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 45 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLWithout Driver |
| signal interface | Single Link TMDS, 35 pins |
| indgangsspænding | 18.0V (Typ.) |
| Ansøgning | DMPC |
