| Varenummer | M270DTN01.0 |
| Mærke | AUO |
| Størrelse | 27.0 |
| Ansøgning | DMPC |
| Løsning | 2560×1440 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M270DTN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 27.0 inch |
| løsning | 2560(RGB)×1440 , Quad-HD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 596.736×335.664 mm |
| omrids | 613.6×356.85×10.9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 3.5/1.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 144Hz |
| lampe type | 18S4PWLEDWithout Driver |
| signal interface | LVDS (8 ch, 8-bit), 130 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
