| Varenummer | MG1561B01-2 |
| Mærke | CSOT |
| Størrelse | 15.6 |
| Ansøgning | Digital Signage |
| Løsning | 1920×1080 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | CSOT |
| modelnavn | MG1561B01-2 |
| skærmstørrelse | 15.6 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 141PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 344.16 × 193.59 (H×V) |
| omrids (mm) | 351.86 × 206.332 × 6.31 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare (Haze 25%), Hard coating (3H) |
| luminans | 250 cd/m² (Typ.) |
| kontrastforhold | 3000 : 1 (Typ.) (TM) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| respons | 30 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | VA, Normally Black, Transmissive |
| farvedybde | 16.7M 72% NTSC |
| baggrundsbelysning | WLED , 15K hours , With LED Driver |
| masse | 530g (Typ.) |
| anvendes til | Digital Signage |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (2 ch, 8-bit) , Connector 40 pins |
| spændingsforsyning | 12.0V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
