| Varenummer | N140FGE-LA2 |
| Mærke | Innolux |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 650:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | N140FGE-LA2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.6×174.15 mm |
| omrids | 320.4×205.1×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 3/7 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| LM12S029 | SHARP | 12.1 | 800×600 |
| LT121DEVCN00 | TOSHIBA | 12.1 | 1280×800 |
| LT121SS-124 | Samsung | 12.1 | 800×600 |
| LTM09C362Z | TOSHIBA | 8.9 | 1024×600 |
| LTN156AT30-B02 | Samsung | 15.6 | 1366×768 |
| N140BGE-L22 | Innolux | 14.0 | 1366×768 |
| N141C3-L02 | Innolux | 14.1 | 1440×900 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N173FGE-L21 | Innolux | 17.3 | 1600×900 |
