| Varenummer | LTM09C362Z |
| Mærke | TOSHIBA |
| Størrelse | 8.9 |
| Ansøgning | NBPC |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Toshiba Matsushita |
| panel model | LTM09C362Z 2 Compatible model |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 8.9 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 195.072×113.4 mm |
| omrids | 224×129×5.2 mm |
| overflade | |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 50/50 (Max.)(Tr/Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 14 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | NBPC |
| B089AW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V3 | AUO | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| LJ089MB2S01 | SHARP | 8.9 | 640×400 |
| LTD089EXWF | TOSHIBA | 8.9 | 1280×768 |
| LTM09C015A | TOSHIBA | 9.4 | 640×480 |
| LTM09C016K | TOSHIBA | 9.4 | 640×480 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTM09C362Z | TOSHIBA | 8.9 | 1024×600 |
| B150XG01 V2 | AUO | 15.0 | 1024×768 |
| B154EW01 V9 | AUO | 15.4 | 1280×800 |
| B156HW01 V7 | AUO | 15.6 | 1920×1080 |
| LP154W01-TLAD | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLC1 | LG Display | 15.4 | 1280×800 |
| LP171WU5-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP173WF1-TLA2 | LG Display | 17.3 | 1920×1080 |
| LTN133AT14-001 | Samsung | 13.3 | 1280×800 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
