| Varenummer | N141I3-L01 |
| Mærke | Innolux |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 450:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N141I3-L01 13 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 303.36×189.6 mm |
| omrids | 319.5×205.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 26%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 3/7 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP141WX1-TLE3 | LG Display | 14.1 | 1280×800 |
| LP141WXV-SLA2 | LG Display | 14.1 | 1280×800 |
| LP141X2 | LG Display | 14.1 | 1024×768 |
| LT141X7-122 | Samsung | 14.1 | 1024×768 |
| LTN141AT12-W03 | Samsung | 14.1 | 1280×800 |
| LTN141BT01-004 | Samsung | 14.1 | 1440×900 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
| N141I3-L01 | Innolux | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| B121EW13 V1 | AUO | 12.1 | 1280×800 |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| B141XG14 V1 | AUO | 14.1 | 1024×768 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP140WD2-TLD2 | LG Display | 14.0 | 1600×900 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| LTN154AT01-A03 | Samsung | 15.4 | 1280×800 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
