| Varenummer | N141I1-L04 |
| Mærke | Innolux |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 240 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N141I1-L04 9 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 303.36×189.6 mm |
| omrids | 319.5×218×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 26%), Hard coating (3H) |
| lysstyrke | 240 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| AA141TC01 | Mitsubishi | 14.1 | 1280×800 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLC1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP3 | LG Display | 14.1 | 1280×800 |
| LTN141BT04-001 | Samsung | 14.1 | 1440×900 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
| N141I3-L01 | Innolux | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| B133XTN01.5 | AUO | 13.3 | 1366×768 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| B154SW02 V3 | AUO | 15.4 | 1680×1050 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LTN150PG-L04 | Samsung | 15.0 | 1400×1050 |
| LTN156AT29-L01 | Samsung | 15.6 | 1366×768 |
| LTN160AT02-002 | Samsung | 16.0 | 1366×768 |
| QD14TL01 Rev.04 | QDI | 14.1 | 1280×800 |
