| Varenummer | N154Z3-L01 |
| Mærke | Innolux |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N154Z3-L01 9 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.128×206.955 mm |
| omrids | 344×222×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| B154SW01 V0 | AUO | 15.4 | 1680×1050 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| LTN154X3-L09-G | Samsung | 15.4 | 1280×800 |
| N154I2-L01 | Innolux | 15.4 | 1280×800 |
| N154I5-L02 | Innolux | 15.4 | 1280×800 |
| N154Z1-L01 | Innolux | 15.4 | 1680×1050 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
| N154Z3-L01 | Innolux | 15.4 | 1680×1050 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B156HW02 V1 | AUO | 15.6 | 1920×1080 |
| HB133WX1-402 | BOE | 13.3 | 1366×768 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP156WH4-TLN2 | LG Display | 15.6 | 1366×768 |
| LTD121KX6B | TOSHIBA | 12.1 | 1280×800 |
| LTN141X7-L06 | Samsung | 14.1 | 1024×768 |
| LTN156AT35-W01 | Samsung | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
