| Varenummer | NV140FHM-N41 |
| Mærke | BOE |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | BOE |
| panel model | NV140FHM-N41 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 309.31×173.99 mm |
| omrids | 320.4×205.1×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S4PWLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B140EW01 V1 | AUO | 14.0 | 1280×768 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP140WH2-TLL2 | LG Display | 14.0 | 1366×768 |
| LP140WH6-TJA1 | LG Display | 14.0 | 1366×768 |
| LP140WH8-TLA1 | LG Display | 14.0 | 1366×768 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| N140BGK-L33 | Innolux | 14.0 | 1366×768 |
| N140HGE-EAA | Innolux | 14.0 | 1920×1080 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
| B133XW01 V3 | AUO | 13.3 | 1366×768 |
| B156RW01 V1 | AUO | 15.6 | 1600×900 |
| B173RW01 V2 HW7A | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A00 | HannStar | 17.3 | 1920×1080 |
| LP125WF2-SPB2 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| LTN140HL02-201 | Samsung | 14.0 | 1920×1080 |
