| Varenummer | NE156QUM-N5G |
| Mærke | BOE |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 3840×2160 |
| Sammensætning | LCM , Oxide TFT-LC |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 12S6P |
| Interface | eDP |
| fabrikant | BOE |
| modelnavn | NE156QUM-N5G (BOE0895) |
| skærmstørrelse | 15.6 inch |
| skærmtype | LCM , Oxide TFT-LCD |
| pixel antal | 3840(RGB)×2160 (UHD) 283PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 344.218 × 193.622 (H×V) |
| omrids (mm) | 350.66 × 205.64 × 4.6 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 340 cd/m² (Typ.) |
| kontrastforhold | 1200 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 30 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | ADS, Normally Black, Transmissive |
| farvedybde | 16.7M 100% sRGB |
| baggrundsbelysning | 12S6P WLED , 20K hours , With LED Driver |
| konturform | Slim (PCBA Bent, T≤3.0mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| CLAA156WA12 | CPT | 15.6 | 1366×768 |
| LP156UD1-SPA2 | LG Display | 15.6 | 3840×2160 |
| LP156WH2-TLAA | LG Display | 15.6 | 1366×768 |
| LP156WHA-SLA2 | LG Display | 15.6 | 1366×768 |
| LTN156AT17-103 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D02 | Samsung | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| N156BGE-L51 | Innolux | 15.6 | 1366×768 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
