| Varenummer | NL12880BC20-25F |
| Mærke | NLT |
| Størrelse | 12.1 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1280×800 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | 3 |
| Interface | LVDS |
| fabrikant | NLT |
| modelnavn | NL12880BC20-25F |
| skærmstørrelse | 12.1 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1280(RGB)×800 (WXGA) 124PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 261.12 × 163.2 (H×V) |
| omrids (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| rammeareal (mm) | 266.1 × 168.2 (H×V) |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 1600 cd/m² (Typ.) |
| kontrastforhold | 800 : 1 (Typ.) (TM) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| respons | 15 (Typ.)(Tr+Td) ms |
| god udsigt kl | 6 o'clock |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 262K/16.7M 50% NTSC |
| baggrundsbelysning | 3 strings WLED , 60K hours , No Driver |
| masse | 470g (Typ.) |
| anvendes til | Industrial Outdoor High Brightness |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LP121WX3-TPB1 | LG Display | 12.1 | 1280×800 |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LQ121S1LG44 | SHARP | 12.1 | 800×600 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
