| Varenummer | NL192108BC18-06F |
| Mærke | NLT |
| Størrelse | 15.6 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1920×1080 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 750:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 4 |
| Interface | eDP |
| fabrikant | NLT |
| modelnavn | NL192108BC18-06F |
| skærmstørrelse | 15.6 inch |
| skærmtype | LCM , a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 141PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 344.16 × 193.59 (H×V) |
| omrids (mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| rammeareal (mm) | 347.55 × 196.75 (H×V) |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 1500 cd/m² (Typ.) |
| kontrastforhold | 750 : 1 (Typ.) (TM) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10) |
| respons | 15/15 (Typ.)(Tr/Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | UA-SFT, Normally Black, Transmissive |
| farvedybde | 16.7M 40% NTSC |
| baggrundsbelysning | 4 strings WLED , 50K hours , No Driver |
| masse | 1.05/1.15Kgs (Typ./Max.) |
| anvendes til | Industrial Outdoor High Brightness |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
