| Varenummer | V201B1-L01 |
| Mærke | Innolux |
| Størrelse | 20.1 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | V201B1-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 444.633×249.984 mm |
| omrids | 473.3×276.7×44.75 mm |
| overflade | Antiglare (Haze 40%), Hard coating (3H), Reflection 2.0% (Max.) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193175% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM201W01-STB1 | LG Display | 20.1 | 1680×1050 |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| M201EW01 V3 | AUO | 20.1 | 1680×1050 |
| M201EW02 V0 | AUO | 20.1 | 1680×1050 |
| M201EW02 VG | AUO | 20.1 | 1680×1050 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| V201B1-L02 | Innolux | 20.1 | 1366×768 |
| BOEV320WX1 | BOE | 31.5 | 1366×768 |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LC260EXN-SDA2 | LG Display | 26.0 | 1366×768 |
| LC370EUN-SDF1 | LG Display | 37 | 1920×1080 |
| LC370EUN-SEF3 | LG Display | 36.5 | 1920×1080 |
| LC420WUN-SAA1 | LG Display | 42 | 1920×1080 |
| LTA230W2-L01 | Samsung | 23.0 | 1366×768 |
| T315HW02 V5 | AUO | 31.5 | 1920×1080 |
| T315XW04 V1 | AUO | 31.5 | 1366×768 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
