| Varenummer | NL4827HC19-05A |
| Mærke | NLT |
| Størrelse | 4.3 |
| Ansøgning | CNS |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | NEC |
| panel model | NL4827HC19-05A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 8/25 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | CMOS (1 ch, 8-bit), 51 pins |
| indgangsspænding | 3.0/5.0V (Typ.)(VCC/VDD) |
| Ansøgning | CNS |
| 70WVW1A | SII | 7.0 | 800×480 |
| A070VW08 V2 | AUO | 7.0 | 800×480 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| C080VW03 V0 | AUO | 8.0 | 800×480 |
| DLC1010GIG | Other | 10.1 | 1280×800 |
| L5F30818P01 | Epson | 6.5 | 800×480 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| T-51965GD088ZU-MFW-AEN | Kyocera | 8.8 | 640×240 |
| TX18D35VM0AAA | KOE | 7.0 | 800×480 |
