| Varenummer | C065GW02 V1 |
| Mærke | AUO |
| Størrelse | 6.5 |
| Ansøgning | CNS |
| Løsning | 400×234 |
| Sammensætning | LCM |
| Lysstyrke | 550 |
| CR | 300:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | AUO |
| panel model | C065GW02 V1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 400(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 143.4×79.326 mm |
| omrids | 155×90.83 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 550 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| indgangsspænding | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Ansøgning | CNS |
| A065VL01 V1 | AUO | 6.5 | 800×480 |
| A065VL01 V2 | AUO | 6.5 | 800×480 |
| C065GW01 V0 | AUO | 6.5 | 400×234 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| C065GW03 V3 | AUO | 6.5 | 400×240 |
| C065GW04 V1 | AUO | 6.5 | 400×240 |
| C065GW04 V2 | AUO | 6.5 | 400×240 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| TX17D01VM2EAB | KOE | 6.5 | 640×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AT065TN14 | Innolux | 6.5 | 800×480 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| C102EVN01.0 | AUO | 10.2 | 1280×720 |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| ND068-101A1 | 6.8 | 1280×480 | |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
