| Varenummer | NT116WHM-N21 |
| Mærke | BOE |
| Størrelse | 11.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | BOE |
| panel model | NT116WHM-N21 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 268×168×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Hard coating (7H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 12 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDEmbedded (LED Driver) |
| signal interface | eDP (1 Lane), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N11 | BOE | 11.6 | 1366×768 |
| NT116WHM-N21 | BOE | 11.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| LP104V2-W | LG Display | 10.4 | 640×480 |
| LP133WH2-TLB2 | LG Display | 13.3 | 1366×768 |
| LP140WF3-SPD1 | LG Display | 14.0 | 1920×1080 |
| LP140WH2-TLA2 | LG Display | 14.0 | 1366×768 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LTD133EX3X | TOSHIBA | 13.3 | 1280×800 |
| LTN150X5-L02 | Samsung | 15.0 | 1024×768 |
| LTN160AT01-F02 | Samsung | 16.0 | 1366×768 |
| N141C3-L02 | Innolux | 14.1 | 1440×900 |
