| Varenummer | NT116WHM-N11 |
| Mærke | BOE |
| Størrelse | 11.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | NT116WHM-N11 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 268×168×3.6 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 12 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116XTB01.0 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| N116B6-L04 | Innolux | 11.6 | 1366×768 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| NT116WHM-N11 | BOE | 11.6 | 1366×768 |
| NT116WHM-N21 | BOE | 11.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| HB133WX1-402 | BOE | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LTD121EA4X | TOSHIBA | 12.1 | 1024×768 |
| LTN140AT22-W02 | Samsung | 14.0 | 1366×768 |
| LTN141X8-L02 | Samsung | 14.1 | 1024×768 |
| N121X5-L06 | Innolux | 12.1 | 1024×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| QD15XL06 Rev.01 | QDI | 15.0 | 1024×768 |
